APPLICATION
Designed for integrated power, data, and optical signal transmission, this hybrid optical fiber cable is used in industrial and communication systems requiring combined electrical, Ethernet, and fiber connectivity with enhanced mechanical protection and LSZH safety.
CONSTRUCTION
|
Conductor Material |
Solid Bare Copper Wire |
|
Conductor Surface / Structure |
Smooth / stranded copper |
|
Core Insulation Material |
LSZH / HDPE (as applicable) |
|
Screen1 Material |
Aluminum foil or copper tape shielding |
|
Drain Material |
Bare or tinned copper drain wire |
|
Screen2 Material |
Braided copper or overall shielding layer |
|
Material Outer Sheath |
LSZH outer sheath |
CHARACTERISTICS
|
Cable performance |
Data of pro duc |
|
(20℃)Inner conductor DC resistance |
14AWG≤8.60Q/km 24AWGs93.80/km |
|
(CAT 5E)lmpedance |
100±150(4-100MHz) |
|
(CAT 5E)Insulationresistance |
>5000MQ-km(20℃ DC 100~500V) |
|
Operatingvoltage |
300V |
|
Optical attenuation @1310nm |
≤0.35dB/km |
|
Min .Bending radiicable |
20×D |
|
Operating Temperature |
-40 to 70℃ |
REGULAR PACKING
100M, 300M, 500M, 1000M, 500FT, 1000FT, Coil/Drum
