Composite 2×1.5mm2+2×G.657A2

Style：Hybrid Optical Fiber Cable
Size: 2×1.5mm2+2×G.657A2
Not every opto-electrical system requires high fiber counts or heavy power capacity. In many installations, the priority is stable optical communication combined with moderate power delivery, while keeping the cable structure simple and easy to deploy. This hybrid optical fiber cable integrates two 1.5 mm² copper conductors with two G.657A2 optical fibers, allowing optical signals and power to be transmitted together in a balanced configuration. The use of LSZH / XLPE insulation and sheath materials supports safer operation in enclosed or public environments where flame performance and material reliability matter.

Send Inquiry

Description

Technical Parameters

Zhejiang Chatnow New Material Technology Co., Ltd. is one of the leading manufacturers and suppliers of composite 2×1.5mm2+2×g.657a2 in China. With abundant experience, we warmly welcome you to wholesale bulk high quality products at competitive price from our factory. We also accept customized orders.

APPLICATION

This cable is commonly used in:

Communication systems requiring optical signal transmission with auxiliary power supply
Industrial equipment where devices need both data and power connection
Integrated opto-electrical installations with moderate load requirements
Infrastructure projects prioritizing safety and clean cable routing

CONSTRUCTION

Conductor Material	Bare copper wire
Conductor Surface	2×1.5mm2+2×G.657A2
Core Insulation Material	LSZH/XLPE
Screen1 Material	PET tape
Drain Material	/
Screen2 Material	/
Material Outer Sheath	LSZH/XLPE

CHARACTERISTICS

Cable performance(20℃)	Data of product
Inner conductor DC resistance	≤12.1Ω/km
Insulation resistance	>1000MQ ·km
Operating voltage	500V
Withstand voltage	AC/2500V 1min
Flame retardancy	IEC 60332-1-2
Bending radius	12xD
Optical attenuation	1310NM ≤0.36 db/km 1550NM ≤0.25 db/km

REGULAR PACKING

100M, 300M, 500M, 1000M, 500FT, 1000FT, Coil/Drum

Product Advantages

Balanced hybrid structure combining power conductors and optical fibers
G.657A2 bend-insensitive fiber supports flexible routing paths
LSZH / XLPE materials improve safety in fire-sensitive environments
Simplified cabling for systems where extreme power or high fiber count is unnecessary
Suitable for fixed installation in communication and industrial systems

Support Available for This Product

Support for customized conductor size or fiber configuration
Stable production scheduling for opto-electrical cable projects
Technical assistance during cable selection and system integration
Samples available for evaluation and testing

FAQ

Q: How is this cable different from hybrid cables with higher fiber counts?
A: This configuration focuses on essential optical communication and moderate power delivery, making it suitable for systems that do not require large fiber capacity.

Q: Why use G.657A2 fiber in hybrid cables?
A: G.657A2 fiber supports tighter bending, which helps maintain performance during installation and routing.

Q: Can insulation or sheath materials be adjusted?
A: Yes. LSZH or XLPE materials can be selected based on project and environmental requirements.
